CVT-TRBO-PP

LTR/Passport GOB application

Digital migration strategy for existing analog trunking users

Learn More

Description

Firmware application for the Generic Option Board to allow the MOTOTRBO radio to support LTR, Classic PassPort and Enhanced PassPort in Analog mode.

Provides a clear migration path from Analog operation to Digital operation for users with existing LTR or PassPort systems/networks.

Benefits
Features
System Requirements

• QA01839, available as a factory installed option in North America.

• Allows users to add digital capable radios to their existing analog fleet to facilitate migration to digital operation.

• Allows users to operate one radio on MOTOTRBO digital platforms (except for Connect Plus) and Analog LTR and/ or PassPort.

• Up to 256 Zones, up to 256 Groups/Channels per Zone.
*Supports over 2000 total Groups/Channels.

• Programming via standard MOTOTRBO USB programming cable.

• Field upgradeable via standard MOTOTRBO USB programming cable.

• (LTR/Conventional) Pre-Only MDC PTT ID.

• (LTR/Conventional) User selectable scanning across Zones.

• (LTR/PassPort) User selectable Group Scan.

• (PassPort) Enhanced and Classic operation.

• (Enhanced PassPort) Integrated network Emergency call operation.

• (Enhanced PassPort) Subscriber priority access.

• (Enhanced PassPort) Automatic Channel backup.

• (Enhanced PassPort) Expanded neighbor list.

• (Enhanced PassPort) Message Trunking.

• (Enhanced PassPort) Roam registration on free channel.

Radio Hardware/Releases Compatibility.

Analog Capable MOTOTRBO radio with a Generic Option Board installed.

Interfaces

A PC running Windows XP or later is required for programming the option board with the winSJIppTRBO programming software using the standard MOTOTRBO programming cable.
