Features
Best-in-class Audio
Loud front-facing speaker and Intelligent Audio feature automatically adjusts the radio volume according to the environment’s noise level.
Day/Night Mode on Display
This display has improved resolution for easier viewing even in broad daylight. It also also features a night mode that makes the screen easier to read in dark environments.
Embedded Bluetooth Audio and Data
Embedded into the radio and enables connectivity with wireless accessories, including Motorola’s unique Operations Critical Wireless earpieces designed for rugged and reliable communications. Share real-time information easily by connecting radios to Bluetooth-enabled data devices.
Text Messaging
Use text messaging when discretion is required or routine communication needs to be delivered without interrupting workers or guests.
Rugged Design
Tightly sealed against wind and dust, and submersible in up to one meter of water for 30 minutes (IP57).
Certified Intrinsically Safe (CSA)
Certified as intrinsically safe by CSA when purchased and equipped with a CSA battery for use in hazardous environments.
Basic or Enhanced Privacy
Built-in scrambling for increased security.
Emergency Button
Orange button on the top of the radio can be programmed to send an alert to a supervisor or dispatcher during an emergency situation.
Transmit Interrupt
Enables a user to interrupt another radio conversation to deliver critical communication exactly when and where it’s needed.
Large, Full-color Display
Features a 5-line color display with a flexible menu-driven interface. Icons and large easy-to-use navigation buttons ease message reading and menu navigation.
Integrated High Efficiency GPS
Use the radio’s integrated GPS receiver to track your vehicles and your workforce. Motorola’s innovative technology gives you higher precision at lower cost, to enhance the safety and accountability of your team.
Productivity-enhancing Data Applications
Features the industry’s largest application developer program to enable a wide variety of customized applications including: location tracking, Bluetooth data, email gateways, dispatch, telephony, man-down and work order ticket management.
Capacity Plus
Single-site digital trunking system that maximizes the capacity of your MOTOTRBO system. Use it to enable a high volume of voice and data communication for over a thousand users at a single site without adding new frequencies.
Linked Capacity Plus
Linked Capacity Plus is an entry level, multi-site digital trunking system configuration for the MOTOTRBO platform. It leverages the high capacity of Capacity Plus, with the wide area coverage capabilities of IP Site Connect to keep your staff at various locations connected with an affordable high capacity, wide area trunking solution.
IP Site Connect
A digital solution that uses the internet to extend the voice and data capabilities of MOTOTRBO. Use it to link up to 15 sites for communication among geographically dispersed locations, to create wide area coverage or enhance coverage at a single site with physical barriers.
Performance Characteristics
-
Frequency band
VHF, UHF-1
-
4 5 Watt
Yes
-
Repeater capable
Yes
-
Estimated battery life
16 hours in digital mode, 12 hours in analog mode
-
Standard battery chemistry type
Lithium Ion
-
1 Watt
Yes
Physical Characteristics
-
Weight with Li-Ion non-FM Battery
27 oz (482 g)
-
Dimensions (HxWxL) with Li-Ion non-FM Battery
5.5 x 2.2 x 1.6in (138.5 x 56.7 x 39.8 mm)
-
Available option board
Yes
-
Emergency button
Yes
-
Keypad
Full
-
Display
Full, Color, Day and night mode
Radio Features
-
Enhanced privacy
Yes
-
Transmit interrupt
Yes
-
Digital private line
Yes
-
Private line
Yes
-
Monitor Permanent (Sticky) Monitor
Yes
-
Lone worker
Yes
-
GPS operation
Yes
-
Voice announcement
Yes
-
Signaling
MDC (Encode/Decode), Quik-Call II (Encode/Decode), DTMF Encode
-
Intelligent audio
Yes
-
Bluetooth
Integrated Bluetooth audio, Integrated Bluetooth data
-
Programmable buttons
Yes
-
Voice operated transmit (VOX)
Yes
-
Time out timer
Yes
-
Talkaround
Yes
-
Text messaging capable
Yes
-
Scan types
Normal, Priority, Dual priority, Nuisance channel delete, Talk group, All group, System, Home revert
-
Phone book
Yes
-
Group call
Yes
-
One to one calling
Yes
-
Missed call alerts
Yes
-
CPS (Customer Programming Software)
Yes
-
Channel spacing
6.25, 12.5, 25
-
Number of channels
1000
-
Channel scan
Yes
-
Caller ID
Yes
-
Call tones
Yes
-
Call forward
Yes
-
Busy channel lockout
Yes
-
Integrated voice and data
Yes
Technology
-
System type
Conventional, TDMA, Capacity Plus, IP Site Connect
-
Digital technology
Yes
User Environment
-
Intrinsic safety standard
CSA certified
-
IP Standards
IP67
-
Submersible
Yes
-
Mil spec
810 C, 810 D, 810 E, 810 F, 810 G
-
Noise reduction software
Yes
Warranty
-
Standard package
Display Portable Radio, Standard Whip with GPS Antenna, IMPRES™ Li-Ion 1800 mAh Battery (CSA), IMPRES single unit charger, 2.5" Belt Clip, Expansion Card, User Guide, Two-year Extended Warranty (Canada only)
-
Standard warranty
2 years
